Step 1 – Download XULRunner: The
Mozilla developer page lists 1.9.2.15
as the most recent release
The XULRunner download is a ZIP file, not a true install. As a
developer, I like the idea that XULRunner only needs to be unzipped
onto my machine. I am assuming that it doesn’t need to hook into my
Windows system and that’s a good thing.
Step 2 – Install XULRunner: I
unzipped the archive to a new “c:\program files\xulrunner” folder.
Pretty simple so far.
Time to start a simple, bare bones application shell. Call it
a XUL
“Hello World” if you want, but I need to make sure that XULRunner will
work at all. Googling turned up a nice tutorial here.
It is definately worth reading. Using the tutorial, I created a simple
bootstrap application. All of what you see below can be found in Ryan’s
tutorial and the Mozilla XULRunner
documentation pages.
Step 3 – Create application folder struture:
I create the root in a new “c:\program files\xulapp” folder. Here is
the subfolder structure:
Notice that there are 4 files in the folder structure:
application.ini, chrome.manifest, prefs.js & main.xul
Step 4 – Setup application.ini:
The application.ini
file acts as the XULRunner entry point for your application. It seems
to be used to configure
how your application intends to use the XULRunner platform as well as
configure some information that XULRunner uses to run your application.
Here is mine:
Step 5 – Setup Chrome Manifest:
The chrome manifest
file is used by XULRunner to define specific URI’s which in turn are
used to locate application resources. This will become clearer when we
see how the “chrome://” URI is used. Applications can be distributed
compressed in a JAR file or uncompressed as folders and files. I am
using the uncompressed method for now. Here is my manifest:
Step 6 – Setup Preferences: The
prefs.js files is used to tell XULRunner the name of the XUL
file to use as the main window. Here is mine:
XULRunner preferences include:
Step 7 – Create some XUL:
Finally, we need to
create a simple XUL window. Nothing fancy here, just the minimum we
need to make a window. No menus or anything:
Step 8 – Run the App: The moment
of truth. We need
to get XULRunner to launch the bare-bones application. From a command
prompt opened to the “c:\program files\myapp” folder, we should be able
to execute this:
Of course, xulrunner.exe must be in the PATH. Because of where
I
unzipped XULRunner, I could also try this if xulrunner.exe is not in
the PATH:
Success! Here is a screenshot of
the bare bones application running on Win2K:
![My App screenshot]()
src="http://starkravingfinkle.org/blog/wp-content/uploads/2006/07/myapp.png">
My next step will be to add much more to the bare bones
application.
I want to explore as much of XUL as I can as fast as I can. For those
that want to skip straight to the end, here is a ZIP of the My App
application:
Mozilla developer page lists 1.9.2.15
as the most recent release
The XULRunner download is a ZIP file, not a true install. As a
developer, I like the idea that XULRunner only needs to be unzipped
onto my machine. I am assuming that it doesn’t need to hook into my
Windows system and that’s a good thing.
Step 2 – Install XULRunner: I
unzipped the archive to a new “c:\program files\xulrunner” folder.
Pretty simple so far.
Time to start a simple, bare bones application shell. Call it
a XUL
“Hello World” if you want, but I need to make sure that XULRunner will
work at all. Googling turned up a nice tutorial here.
It is definately worth reading. Using the tutorial, I created a simple
bootstrap application. All of what you see below can be found in Ryan’s
tutorial and the Mozilla XULRunner
documentation pages.
Step 3 – Create application folder struture:
I create the root in a new “c:\program files\xulapp” folder. Here is
the subfolder structure:
/xulapp
/chrome
/content
main.xul
chrome.manifest
/defaults
/preferences
prefs.js
application.ini
Notice that there are 4 files in the folder structure:
application.ini, chrome.manifest, prefs.js & main.xul
Step 4 – Setup application.ini:
The application.ini
file acts as the XULRunner entry point for your application. It seems
to be used to configure
how your application intends to use the XULRunner platform as well as
configure some information that XULRunner uses to run your application.
Here is mine:
[App]
Vendor=Finkle
Name=Test App
Version=1.0
BuildID=20060101
Copyright=Copyright (c) 2006 Mark Finkle
ID=xulapp@starkravingfinkle.org
[Gecko]
MinVersion=1.8
MaxVersion=1.8
Step 5 – Setup Chrome Manifest:
The chrome manifest
file is used by XULRunner to define specific URI’s which in turn are
used to locate application resources. This will become clearer when we
see how the “chrome://” URI is used. Applications can be distributed
compressed in a JAR file or uncompressed as folders and files. I am
using the uncompressed method for now. Here is my manifest:
content myapp file:content/Step 6 – Setup Preferences: The
prefs.js files is used to tell XULRunner the name of the XUL
file to use as the main window. Here is mine:
pref("toolkit.defaultChromeURI",
"chrome://myapp/content/main.xul");XULRunner preferences include:
Step 7 – Create some XUL:
Finally, we need to
create a simple XUL window. Nothing fancy here, just the minimum we
need to make a window. No menus or anything:
<?xml version="1.0"?>
<?xml-stylesheet href="chrome://global/skin/" type="text/css"?>
<window id="main" title="My App" width="300" height="300"
xmlns="http://www.mozilla.org/keymaster/gatekeeper/there.is.only.xul">
<caption label="Hello World"/>
</window>
Step 8 – Run the App: The moment
of truth. We need
to get XULRunner to launch the bare-bones application. From a command
prompt opened to the “c:\program files\myapp” folder, we should be able
to execute this:
xulrunner.exe application.iniOf course, xulrunner.exe must be in the PATH. Because of where
I
unzipped XULRunner, I could also try this if xulrunner.exe is not in
the PATH:
..\xulrunner\xulrunner.exe application.iniSuccess! Here is a screenshot of
the bare bones application running on Win2K:
src="http://starkravingfinkle.org/blog/wp-content/uploads/2006/07/myapp.png">
My next step will be to add much more to the bare bones
application.
I want to explore as much of XUL as I can as fast as I can. For those
that want to skip straight to the end, here is a ZIP of the My App
application:
